GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Hard to believe the GLUE chip is bad, but with the correct clock signals at the those locations you showed above, the ROM slot should... -
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Do you see a good square wave for C3 and the E clock, at UI8 GLUE chip?
-
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Good point, never asked if this was a V5 Reloaded board. @Steve Rieck , In the first post it says all your clock signals are good...
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Where are you clipping your scope ground to? Can you widen the picture to show your entire probe setup?
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.The ROM slot should be getting a solid square wave, what does Pin 4 of the ROM slot show? Make sure to press the Reset button a couple...
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Starting on Page 46 of the PDF, or Page 45 and 46 of the Simasimac Repair Guide: are you able to see the clock signals in the ROM slot...
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.Have you checked all of the Reset pins yet? UB10 and 11 only Reset on Pin 5, don't worry about Pin 6.
-
-
GreenBar0n replied to the thread Anyone wanna help me troubleshoot my Simasimac Reloaded SE/30 board?.According to the Simasimac Repair Guide, everything starts with the ASC UE10 chip, the Reset line is released from there before anything...
-
